Super Atlas FM80PT

Super Atlas FM80PT; Vanguard; Hospitalet (ID = 372871) Radio Super Atlas FM80PT; Vanguard; Hospitalet (ID = 372872) Radio
Super Atlas FM80PT; Vanguard; Hospitalet (ID = 1244307) Radio Super Atlas FM80PT; Vanguard; Hospitalet (ID = 1245666) Radio
Super Atlas FM80PT; Vanguard; Hospitalet (ID = 1245667) Radio Super Atlas FM80PT; Vanguard; Hospitalet (ID = 1805824) Radio
Super Atlas FM80PT; Vanguard; Hospitalet (ID = 1952694) Radio Super Atlas FM80PT; Vanguard; Hospitalet (ID = 1952695) Radio
Super Atlas FM80PT; Vanguard; Hospitalet (ID = 1952696) Radio
Use red slider bar for more.
Super Atlas FM80PT; Vanguard; Hospitalet (ID = 372871) Radio
Vanguard; Hospitalet: Super Atlas FM80PT [Radio] ID = 372871 613x364
Select picture or schematic to display from thumbnails on the right and click for download.
For model Super Atlas FM80PT, Vanguard; Hospitalet de Llobregat:
FRONT

Country:  Spain
Manufacturer / Brand:  Vanguard; Hospitalet de Llobregat
alternative name

Cahué Industrial
Year: 1977 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 12:
schematic requested
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 125/220 ; 4x1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4.5 inch = 11.4 cm
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Super Atlas FM80PT - Vanguard; Hospitalet de
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Net weight (2.2 lb = 1 kg) 1 kg / 2 lb 3.2 oz (2.203 lb)
Source of data - - Data from my own collection
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Salvador Saura-Lopez. See "Data change" for further contributors.



All listed radios etc. from Vanguard; Hospitalet de Llobregat
Here you find 95 models, 65 with images and 74 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
