• Country
• Italy

• Manufacturer / Brand
• Watt Radio; Torino

• Year
• 1958 ??

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 144161

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 20

• Valves / Tubes
• 6BK7A 12AT7 6AU6 6AU6 6AU6 6AU6 EL41 6AU6 EQ80 EL41 6AU6 PCL82 ECL80 6SN7 6BQ6GA 6AX4 1B3GT 5U4GA 6FX4 AW53-80 or 21ALP4A

• Number of Transistors

• Semiconductors
• OA70

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 110-220 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: WR21/12/C - Watt Radio; Torino

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 600 x 580 x 500 mm / 23.6 x 22.8 x 19.7 inch

• Notes

• Televisore 21" 90°.

  Televisore in bianco/nero con sola VHF.
  Doppio ingresso per l'antenna: Normale o attemuato in caso di segnali fortissimi.

  Cinescopio da 21 pollici con deflessione 90°.

  Lo stesso schema era utilizzato per WR17/12/C con cinescopio da 17 pollici

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Alessandro De Poi. See "Data change" for further contributors.
