UL11

Information - Help
ID = 716

Country:
Germany
Brand: Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Developer: Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Tube type:  Vacuum Pentode   Power/Output
Identical to UL11
Similar Tubes
Heater different:
  PL11
Other base:
  UL41
First year 1950 Tube leaflet collection E.Erb Analysis by original leaflets
First Source (s)
May.1950 : Funkschau # 11
Predecessor Tubes CL4
Successor Tubes 1947   UL41   UL84   UL171

Base German Steel Y8A, 1938
Was used by Radio/TV-reception etc.
Filament Vf 45 Volts / If 0.1 Ampere / Indirect / Series, AC/DC
Dimensions (WHD)
incl. pins / tip
37 x 109 x mm / 1.46 x 4.29 x inch
Tube prices 1 Tube prices (visible for members only)

UL11: RR
Reinhard Riek


UL11: Telefunken Werkstattbuch
Wolfgang Bauer


UL11: Lorenz Empfänger - Röhren
Anonymous 54 Collector


Usage in Models 1= 1942? ; 1= 1950? ; 26= 1950 ; 7= 1951 ; 1= 1952? ; 2= 1952 ; 1= 1954

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):39
