• Country
• Germany

• Manufacturer / Brand
• Argus Radiowerk, Heribert Schulten; Orsoy (Niederrhein)

• Year
• 1953/1954

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 19952

• Number of Tubes
• 18

• Valves / Tubes
• PCC84 PCF82 EF80 EF80 EF80 EB41 EL41 EF80 EABC80 EL41 ECL80 ECC82 EL41 ECC82 PL81 PY81 EY51 MW36-44

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Capitol W [7 Kanäle] - Argus Radiowerk, Heribert

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 630 x 410 x 350 mm / 24.8 x 16.1 x 13.8 inch

• Notes
• VHF TV-Bereiche

• Net weight (2.2 lb = 1 kg)
• 26 kg / 57 lb 4.3 oz (57.269 lb)

• Price in first year of sale
• 935.00 DM

• External source of data
• Erb

• Source of data
• Kat.d.Rundf.GrossH.1953/54 / Radiokatalog Band 2, Ernst Erb
