For model Arkansas 57 4345 hell, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1956/1957 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 EC92 ECH81 EF89 EM80 EABC80 EL84
Main principle Super-Heterodyne (Super in general)
Tuned circuits 7 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110; 127; 155; 220; 240 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Arkansas 57 4345 [hell] - Blaupunkt Ideal, Berlin,
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 1190 x 910 x 454 mm / 46.9 x 35.8 x 17.9 inch
Notes

Phono-Chassis = Perpetuum-Ebner Rex A. Katalog und Prospekte zeigen andere Lautsprecherbespannung als reale Modelle.

Cabinet model 4345 Chassis model 2340: Includes "MW Saugkreis" internally mounted at back of chassis beside antenna connector and an extended "sopranregler" design, see my pictures. These features are not seen in later Arkansas models, e.g. 4430/4431.

Moreover, my 4345 does not state "Arkansas 57" on the back wall, just "Arkansas"

Net weight (2.2 lb = 1 kg) 44.5 kg / 98 lb 0.3 oz (98.018 lb)
Price in first year of sale 840.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1956/57
