• Country
• Germany

• Manufacturer / Brand
• Blaupunkt (Ideal), Berlin, später Hildesheim

• Year
• 1962/1963

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 75744

• • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
  • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 17

• Valves / Tubes
• PCC88 PCF82 PC88 PC86 EF80 EF85 EF80 EF184 PCL86 PCL84 ECH84 PCL85 ECH84 PL36 PY88 DY86 AW47-91

• Number of Transistors

• Semiconductors
• OA180 OA159 OA79 OA79 OA161 K5/62 K1,5/20 E50C5 E50C5 OY241

• Main principle
• Superheterodyne (common); ZF/IF 38900 kHz

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 inch = 33 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: Toskana de Luxe 72110 [47 cm] - Blaupunkt Ideal, Berlin,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 480 x 400 x 340 mm / 18.9 x 15.7 x 13.4 inch

• Notes
• VHF/UHF.

• Net weight (2.2 lb = 1 kg)
• 21 kg / 46 lb 4.1 oz (46.256 lb)

• Price in first year of sale
• 998.00 DM

• Source of data
• Handbuch VDRG 1962/1963

• Literature/Schematics (1)
• -- Original-techn. papers. (Kundendienstschrift, Fernseher 1962/63)

• Author
• Model page created by Hugo Sneyers. See "Data change" for further contributors.
