- Manufacturer / Brand
- Emud, Ernst Mästling; Ulm
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Tuned circuits
- 6 AM circuit(s) 10 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 150; 180; 220 Volt
- 3 Loudspeakers
- Power out
- 6 W (unknown quality)
- Wooden case
- from Radiomuseum.org
- Model: Rekord-Senior 60 - Emud, Ernst Mästling; Ulm
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 530 x 320 x 250 mm / 20.9 x 12.6 x 9.8 inch
Das Modell Emud Rekord-Senior 60 von Ernst Mästling, Ulm, wurde auch in einer Export-Version ohne Langwellen gebaut. KW ist dort von 5.9 bis 10 MHz.
Siehe auch Rekord Senior 60 Export.
- Net weight (2.2 lb = 1 kg)
- 9.3 kg / 20 lb 7.8 oz (20.485 lb)
- Price in first year of sale
- 269.00 DM
- External source of data
- Source of data
- HdB d.Rdf-& Ferns-GrH 1959/60
- Mentioned in
- -- Schematic
- Other Models
Here you find 420 models, 326 with images and 229 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Emud, Ernst Mästling; Ulm
Forum contributions about this model: Emud, Ernst Mästling: Rekord-Senior 60
Threads: 1 | Posts: 4
It has been a while since I wrote to RM.org. I have been talking up this site and sending people here for help. It is nice to be back.
I am aligning the FM section of an American Emud 60. There is a problem with getting the proper alignment instructions for this three band (AM, FM, SW) unit. I am using the Sams Photofact procedure from the Emud Junior to cross reference the test pins.
If you reference the schematic from the Emud Senior 60 (on this web site) the problem is with getting a DC zero voltage null with adjustment #21 at unmodulated 10.7 Mhz signal across test points B and C.
There also seems to be great interaction between adjustment 21 (null) and 19 (peak).
I am beginning to think that I am miss adjusting the unit or there is a bad component (EABC80 tube has been tested with a Heath Kit emissions tester). Any suggestions would be appreciated.
It is 0008 in the morning. So I decided to turn off the power in the shop, write this message and get some sleep.
