Kurfürst F44

Kurfürst F44; Graetz, Altena (ID = 246741) TV Radio

Kurfürst F44; Graetz, Altena (ID = 246742) TV Radio

Kurfürst F44; Graetz, Altena (ID = 246743) TV Radio

Kurfürst F44; Graetz, Altena (ID = 246744) TV Radio

Kurfürst F44; Graetz, Altena (ID = 246745) TV Radio

Kurfürst F44; Graetz, Altena (ID = 246746) TV Radio

Kurfürst F44; Graetz, Altena (ID = 246747) TV Radio

Kurfürst F44; Graetz, Altena (ID = 246748) TV Radio

Kurfürst F44; Graetz, Altena (ID = 246749) TV Radio

Kurfürst F44; Graetz, Altena (ID = 246750) TV Radio
Kurfürst F44; Graetz, Altena (ID = 1425794) TV Radio Kurfürst F44; Graetz, Altena (ID = 737767) TV Radio
Kurfürst F44; Graetz, Altena (ID = 283451) TV Radio Kurfürst F44; Graetz, Altena (ID = 737776) TV Radio
Kurfürst F44; Graetz, Altena (ID = 231746) TV Radio Kurfürst F44; Graetz, Altena (ID = 737774) TV Radio
Kurfürst F44; Graetz, Altena (ID = 737775) TV Radio Kurfürst F44; Graetz, Altena (ID = 737777) TV Radio
Kurfürst F44; Graetz, Altena (ID = 737778) TV Radio Kurfürst F44; Graetz, Altena (ID = 1330033) TV Radio
Use red slider bar for more.
Kurfürst F44; Graetz, Altena (ID = 1425794) TV Radio
Graetz, Altena: Kurfürst F44 [TV Radio] ID = 1425794 933x1180
Select picture or schematic to display from thumbnails on the right and click for download.
For model Kurfürst F44, Graetz, Altena (Westfalen)

Country:  Germany
Manufacturer / Brand:  Graetz, Altena (Westfalen)
Year: 1957/1958 Category: Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
Valves / Tubes 23: UCC85 UCH81 UBF80 UF89 UM80 UL84 PCC88 PCF80 PL83 PCF80 EF80 EF80 EF80 EF80 ECC82 EH90 ECH81 PCL82 PL36 PY81 EY86 AW53-80
Main principle Super-Heterodyne (Super in general); ZF/IF 38900/5500/472 kHz
Wave bands Wave Bands given in the notes.
Details Radio Control (+Remote Wire etc)
Power type and voltage AC/DC-set / 220 Volt
Loudspeaker 3 Loudspeakers
Power out 6 W (unknown quality)
from Radiomuseum.org Model: Kurfürst F44 - Graetz, Altena Westfalen
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 700 x 966 x 548 mm / 27.6 x 38 x 21.6 inch
Notes Graetz Kurfürst F44;
Radio: LMKU; TV: nur VHF.
Gemeinsamer FM-ZF Verstärker für UKW und Fernsehton.
Net weight (2.2 lb = 1 kg) 59 kg / 129 lb 15.3 oz (129.956 lb)
Price in first year of sale 1'568.00 DM
Collectors' prices
Source of data HdB d.Rdf-& Ferns-GrH 1957/58
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Hilmer Grunert. See "Data change" for further contributors.
