For model Dacapo UKW, Hartenstein, Walter, WHM ; Mühltroff (Vogtland)

Country:  Germany
Manufacturer / Brand:  Hartenstein, Walter, WHM ; Mühltroff (Vogtland)
Year: 1962 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 EF80 EF89 EABC80 EM80 EL84 EZ80
Main principle Superheterodyne (common)
Tuned circuits 9 FM circuit(s)
Wave bands FM Broadcast Band Only
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 8 W (unknown quality)
from Radiomuseum.org Model: Dacapo UKW - Hartenstein, Walter, WHM ;
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 560 x 355 x 230 mm / 22 x 14 x 9.1 inch
Notes Tasten als Klangregister. Kleinserie. Chassis auch in Musikschränken Fa. Peter, Plauen.Verschiedene Gehäusevarianten mit identischem Chassis;auch ohne eingebauten Lautsprecher und ohne eingebauten Ausgangsübertrager.Hier Anschluß der Ausgangsübertrager für 1.und 2.Ls über Bananensteckerbuchsen am Chassis.
Net weight (2.2 lb = 1 kg) 10.9 kg / 24 lb 0.1 oz (24.009 lb)
Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in Radio-Chronik

Model page created by Wolfgang Eckardt. See "Data change" for further contributors.
