Supra-Selector 39W bis Nr. 872000

Supra-Selector 39W; Körting-Radio; (ID = 196630) Radio

Supra-Selector 39W; Körting-Radio; (ID = 196631) Radio

Supra-Selector 39W; Körting-Radio; (ID = 196632) Radio

Supra-Selector 39W; Körting-Radio; (ID = 196633) Radio

Supra-Selector 39W; Körting-Radio; (ID = 196634) Radio

Supra-Selector 39W; Körting-Radio; (ID = 196635) Radio

Supra-Selector 39W; Körting-Radio; (ID = 196636) Radio

Supra-Selector 39W; Körting-Radio; (ID = 14296) Radio

Supra-Selector 39W; Körting-Radio; (ID = 14297) Radio

Supra-Selector 39W; Körting-Radio; (ID = 4755) Radio
Supra-Selector 39W; Körting-Radio; (ID = 83804) Radio Supra-Selector 39W; Körting-Radio; (ID = 19726) Radio
Supra-Selector 39W; Körting-Radio; (ID = 19727) Radio Supra-Selector 39W; Körting-Radio; (ID = 707894) Radio
Supra-Selector 39W; Körting-Radio; (ID = 3233) Radio Supra-Selector 39W; Körting-Radio; (ID = 159634) Radio
Supra-Selector 39W; Körting-Radio; (ID = 159635) Radio Supra-Selector 39W; Körting-Radio; (ID = 196987) Radio
Supra-Selector 39W; Körting-Radio; (ID = 196988) Radio Supra-Selector 39W; Körting-Radio; (ID = 196989) Radio
Use red slider bar for more.
Supra-Selector 39W; Körting-Radio; (ID = 83804) Radio
Körting-Radio;: Supra-Selector 39W [Radio] ID = 83804 876x658
Select picture or schematic to display from thumbnails on the right and click for download.
For model Supra-Selector 39W bis Nr. 872000, Körting-Radio; Leipzig, später Grassau

Country:  Germany
Manufacturer / Brand:  Körting-Radio; Leipzig, später Grassau
alternative name

Dietz & Ritter GmbH, Dr.
Year: 1938/1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: EF13 ECH11 EBF11 EL12 EFM11 AZ12
Main principle Superhet with RF-stage; ZF/IF 468 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Supra-Selector 39W [bis Nr. 872000] - Körting-Radio; Leipzig, später
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 565 x 448 x 320 mm / 22.2 x 17.6 x 12.6 inch
Notes ab Nr.872001 and.Sch.;var.BBr.
Net weight (2.2 lb = 1 kg) 23 kg / 50 lb 10.6 oz (50.661 lb)
Price in first year of sale 423.00 RM
Source of data Handbuch WDRG 1938 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange+Schenk+FS-Röhrenbestückung
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.
