Meran Ch= 609 TV-Ch= FS1021SL
Kuba (Kuba-Imperial), G. Kubetschek; Wolfenbüttel
- Country
- Germany
- Manufacturer / Brand
- Kuba (Kuba-Imperial), G. Kubetschek; Wolfenbüttel
- Year
- 1959/1960
- Category
- Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
- Radiomuseum.org ID
- 101309
-
- alternative name: Imperial Kuba
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 30
- Valves / Tubes
- ECC85 ECH81 EF85 EABC80 EM84 EC92 ECL82 ECL82 PCC88 PCF82 EF80 EF80 EF80 EF80 EF80 PL83 EF80 EF80 PABC80 PL84 PCF80 PCF82 PC92 ECH81 PCF80 PCL82 PL36 PY88 DY86 AW53-88
- Number of Transistors
- Main principle
- Superheterodyne (common); ZF/IF 38900/460/10700 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Details
- Changer (Record changer); Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- 6 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Meran Ch= 609 TV-Ch= FS1021SL - Kuba Kuba-Imperial, G.
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 1200 x 990 x 470 mm / 47.2 x 39 x 18.5 inch
- Notes
-
First 8 tubes and B250C200 semiconductor belong to Radio-Chassis J609
VHF; gegen Aufpreis mit UHF-Tuner lieferbar.
Fernseh-Chassis = FS1021SL mit motorisierter Kanalwählerautomatik.
Rundfunk-Chassis = Vollstereo-Super 609;
Phono-Chassis = Telefunken TW501 Stereo.
- Net weight (2.2 lb = 1 kg)
- 99 kg / 218 lb 1 oz (218.062 lb)
- Price in first year of sale
- 1,968.00 DM
- Source of data
- HdB d.Rdf-& Ferns-GrH 1959/60
- Author
- Model page created by Bernd P. Kieck. See "Data change" for further contributors.
