• Country
• Germany

• Manufacturer / Brand
• Metz Transformatoren- und Apparatefabrik (ex TAM), Fürth

• Year
• 1961/1962

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 323573

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 17

• Valves / Tubes
• PC88 PC86 PCC88 PCF82 EF80 EF80 EF80 PCL84 EF80 PCL86 ECH84 PCL85 PCF80 PL36 PY88 DY86 AW59-90

• Number of Transistors

• Semiconductors
• K5/2 K5/105 K5/105 OA81 M3 V40C1 E220C350

• Main principle
• Superhet with RF-stage; ZF/IF 38900/33400/5500 kHz

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Details
• Radio Control (+Remote Wire etc)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Capri Vollautomatik 867 UHF - Metz Transformatoren- und

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 670 x 480 x 340 mm / 26.4 x 18.9 x 13.4 inch

• Notes

• Lautsprecher: 1x perm.-dyn. 18x13cm seitlich, 1x el.-stat. 8,5cm Ø vorn.
  Anschluss für Aussenlautsprecher.

  Ausführungen: Nussbaum dunkel poliert, Nussbaum hell mattiert (1057,-DM),
  jeweils mit zweifarbigen Fronteinsatz aus Kunststoff.
  Anschraubbare Beine: 26,-DM
  Fernbedienung FB112 23,-DM

• Net weight (2.2 lb = 1 kg)
• 33.5 kg / 73 lb 12.6 oz (73.789 lb)

• Price in first year of sale
• 1,049.00 DM

• Mentioned in
• Handbuch RFP 1961/62 (S.91)

• Literature/Schematics (1)
• HdB d.Rdf-& Ferns-GrH 1961/62 (S.A58)

• Author
• Model page created by Manfred Rathgeb. See "Data change" for further contributors.
