Minerphon Supreme W

Minerphon Supreme W; Minerva-Radio (ID = 58558) Radio Minerphon Supreme W; Minerva-Radio (ID = 97275) Radio
Minerphon Supreme W; Minerva-Radio (ID = 97276) Radio Minerphon Supreme W; Minerva-Radio (ID = 97277) Radio
Minerphon Supreme W; Minerva-Radio (ID = 97278) Radio Minerphon Supreme W; Minerva-Radio (ID = 972971) Radio
Minerphon Supreme W; Minerva-Radio (ID = 972972) Radio Minerphon Supreme W; Minerva-Radio (ID = 972973) Radio
Minerphon Supreme W; Minerva-Radio (ID = 972974) Radio Minerphon Supreme W; Minerva-Radio (ID = 972975) Radio
Use red slider bar for more.
Minerphon Supreme W; Minerva-Radio (ID = 58558) Radio
Minerva-Radio: Minerphon Supreme W [Radio] ID = 58558 692x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Minerphon Supreme W, Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien:
Sammlung A. Fröhlich

Country:  Austria
Manufacturer / Brand:  Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien
Year: 1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: EF80 EC92 ECH81 EF85 EM34 EABC80 EL84 EZ80
schematic requested
Main principle Superheterodyne (common)
Tuned circuits 7 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details Record Player (perh.Changer)
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Minerphon Supreme W - Minerva-Radio Radiola-
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 590 x 400 x 340 mm / 23.2 x 15.7 x 13.4 inch
Notes

Minerva 8-Röhren-Drucktasten-UKW-Vollsuper Modell Minerphon Supreme W.

  • Dreistufiger Klangschalter
  • Baß-, Mittel- und Hochtonlautsprecher
  • Plattenspieler mit 3 Geschwindigkeiten (33, 45 & 78 U/min.)
    • Laufwerk Fa. Philips. oder ELAC
    • Kristall-Tonabnehmer mit umschaltbarem Doppel-Saphir.
  • Gehäuse: Nußholz

Siehe auch:

Net weight (2.2 lb = 1 kg) 19.7 kg / 43 lb 6.3 oz (43.392 lb)
Price in first year of sale 3'400.00 ATS
External source of data A. Fröhlich, Graz
Source of data -- Original prospect or advert / Radiokatalog Band 2, Ernst Erb

Model page created by Ernst Erb. See "Data change" for further contributors.



All listed radios etc. from Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien
Here you find 627 models, 557 with images and 446 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
