• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1958/1959

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 75108

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 22

• Valves / Tubes
• PCC88 PCF82 EF80 EF80 PM84 EF80 EF80 PL83 EF80 ECC82 EF80 EF80 PABC80 PL84 ECL80 ECC82 ECH81 PL36 PY81 DY86 PCL82 AW53-80

• Main principle
• Superheterodyne (common); ZF/IF 38900 kHz

• Wave bands
• Wave Bands given in the notes.

• Details
• Radio Control (+Remote Wire etc)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Souverän 59 Ch= L59 - Nordmende, Norddeutsche Mende-

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 615 x 910 x 540 mm / 24.2 x 35.8 x 21.3 inch

• Notes
• FS-Band I und III. Technische Daten wie Diplomat 59, jedoch mit 53-cm-Bilröhre im Standgehäuse. Fernbedienung DM 26.- extra.
  Das Prospektblatt (s.Bild) nennt irrtümlich 23 Röhren. Es sind aber nur 22 (lt.Schaltbild und Katalogangabe).

• Net weight (2.2 lb = 1 kg)
• 53 kg / 116 lb 11.8 oz (116.74 lb)

• Price in first year of sale
• 1,298.00 DM

• Source of data
• HdB d.Rdf-& Ferns-GrH 1958/59

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by Günter Kaulfuß. See "Data change" for further contributors.
