Radio Gramophone FS 865 A

Radio Gramophone FS 865 A; Philips, Svenska AB, (ID = 1320941) Radio

Radio Gramophone FS 865 A; Philips, Svenska AB, (ID = 1320942) Radio

Radio Gramophone FS 865 A; Philips, Svenska AB, (ID = 1320943) Radio
Radio Gramophone FS 865 A; Philips, Svenska AB, (ID = 1319843) Radio Radio Gramophone FS 865 A; Philips, Svenska AB, (ID = 1319845) Radio
Radio Gramophone FS 865 A; Philips, Svenska AB, (ID = 1319847) Radio Radio Gramophone FS 865 A; Philips, Svenska AB, (ID = 1319852) Radio
Radio Gramophone FS 865 A; Philips, Svenska AB, (ID = 1320944) Radio
Use red slider bar for more.
Radio Gramophone FS 865 A; Philips, Svenska AB, (ID = 1319843) Radio
Philips, Svenska AB,: Radio Gramophone FS 865 A [Radio] ID = 1319843 933x621
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radio Gramophone FS 865 A, Philips, Svenska AB, Stockholm

Country:  Sweden
Manufacturer / Brand:  Philips, Svenska AB, Stockholm
Year: 1956 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 9: ECC85 ECH81 EBF80 EF89 EM80 EABC80 EC92 EL84 EL84
Semiconductors (the count is only for transistors) Tr.Gl.=Metal-rectif.
Main principle Super-Heterodyne (Super in general)
Tuned circuits 6 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker 3 Loudspeakers
Power out 6 W (unknown quality)
from Radiomuseum.org Model: Radio Gramophone FS 865 A - Philips, Svenska AB, Stockholm
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Dimensions (WHD) 962 x 764 x 405 mm / 37.9 x 30.1 x 15.9 inch
Notes

"Bi-Ampli" af amplifier.

Net weight (2.2 lb = 1 kg) 40 kg / 88 lb 1.7 oz (88.106 lb)
Source of data - - Manufacturers Literature

Model page created by Ola Gröndalen. See "Data change" for further contributors.
