For model Cranach FE866A, Rafena Werke Radeberg, VEB; Radeberg (Ostd.):
Prospektbild

Country:  Germany
Manufacturer / Brand:  Rafena Werke Radeberg, VEB; Radeberg (Ostd.)
Brand

VEB Rafena; Radeberg (Ostd.)
Year: 1958 Category: Television Receiver (TV) or Monitor
Valves / Tubes 19: ECC85 ECH81 EF80 EABC80 EL84 ECF82 ECC84 EL83 EH90 ECC82 EL81 EY81 DY86 ECL82 B43M1
Main principle Superheterodyne (common); ZF/IF 5500/38900 kHz
Tuned circuits 11 FM circuit(s)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker 2 Loudspeakers
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Cranach FE866A - Rafena Werke Radeberg, VEB;
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 620 x 550 x 510 mm / 24.4 x 21.7 x 20.1 inch
Notes 12-Kanal-Kaskodetuner VHF. Fernsehgerät mit UKW Teil. Röhren EF80 und ECF82 sind mehrfach vorhanden. Bildröhre auch MW43-69. Siehe auch Modell "Forum FE863H". Selbes Chassis im Standgehäuse ohne Rundfunkteil. Drehbarer Dipol eingebaut.
Price in first year of sale 1'770.00 DM
Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in -- Original prospect or advert
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Jörg Kulbe. See "Data change" for further contributors.
