Schauinsland T645; SABA; Villingen (ID = 972043) Television

Schauinsland T645; SABA; Villingen (ID = 972044) Television
Schauinsland T645; SABA; Villingen (ID = 232848) Television
Use red slider bar for more.
Schauinsland T645; SABA; Villingen (ID = 232848) Television
SABA; Villingen: Schauinsland T645 [Television] ID = 232848 230x201
Select picture or schematic to display from thumbnails on the right and click for download.
For model Schauinsland T645, SABA; Villingen

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1957/1958 Category: Television Receiver (TV) or Monitor
Valves / Tubes 16: PCC88 PCF82 EF80 EF80 EF80 PCL81 EF80 EF80 EABC80 PCL82 ECL80 PCL82 PL36 PY83 EY86 MW53-80
Main principle Super-Heterodyne (Super in general); ZF/IF 38900 kHz
Wave bands Wave Bands given in the notes.
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
Power out
from Radiomuseum.org Model: Schauinsland T645 - SABA; Villingen
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 630 x 580 x 480 mm / 24.8 x 22.8 x 18.9 inch
Notes Das Tischgerät Schauinsland T645 ist eine Weiterentwicklung des T605. Der VHF- Tuner erhielt eine PCC88. Empfangen werden die Kanäle 2 bis 11. Mittels Fernbedienung lassen sich Helligkeit und Lautstärke einstellen.
Net weight (2.2 lb = 1 kg) 42 kg / 92 lb 8.2 oz (92.511 lb)
Price in first year of sale 1'098.00 DM
Source of data HdB d.Rdf-& Ferns-GrH 1957/58

Model page created by Bernd P. Kieck. See "Data change" for further contributors.
