• Country
• Belgium

• Manufacturer / Brand
• Siera; Belgien

• Year
• 1962 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 175101

• Number of Tubes
• 9

• Valves / Tubes
• ECC85 ECH81 EF89 EF85 EM80 EABC80 EL84 EL86 EZ80

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 125/220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch

• Material
• Bakelite case

• from Radiomuseum.org
• Model: SA-3030A - Siera; Belgien

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 530 x 360 x 210 mm / 20.9 x 14.2 x 8.3 inch

• Author
• Model page created by Diego Fernandez-Fernandez. See "Data change" for further contributors.

• Other Models

• Here you find 452 models, 413 with images and 181 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Siera; Belgien
