Admiral 346W (T346W)

Admiral 346W ; Telefunken (ID = 21733) Radio

Admiral 346W ; Telefunken (ID = 243907) Radio

Admiral 346W ; Telefunken (ID = 243909) Radio

Admiral 346W ; Telefunken (ID = 243911) Radio

Admiral 346W ; Telefunken (ID = 21734) Radio

Admiral 346W ; Telefunken (ID = 7623) Radio

Admiral 346W ; Telefunken (ID = 718160) Radio

Admiral 346W ; Telefunken (ID = 718161) Radio
Admiral 346W ; Telefunken (ID = 1769772) Radio
Use red slider bar for more.
Admiral 346W ; Telefunken (ID = 1769772) Radio
Telefunken: Admiral 346W [Radio] ID = 1769772 1197x683
Select picture or schematic to display from thumbnails on the right and click for download.
For model Admiral 346W (T346W), Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH:
Telefunken Prospekt Code: "134 E.ZUFN" (Jan. 1934 ???)

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1933/1934 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: RENS1234 RENS1234 REN914 RENS1374d RGN1064
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown); 2 Special; 1 AF stage(s); Anode bend detection
Tuned circuits 3 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Admiral 346W - Telefunken Deutschland TFK,
Material Bakelite case
Shape Tablemodel, Box - most often with Lid (NOT slant panel).
Dimensions (WHD) 440 x 325 x 305 mm / 17.3 x 12.8 x 12 inch
Notes

Paralleltype zum AEG Ultra-Geadem 304W in anderem Gehäuse.
Paralleltype zum Siemens Ätherzepp 47W in anderem Gehäuse.

Price in first year of sale 233.00 RM !
Collectors' prices
Source of data Radio-Zentrale Prohaska 1933/34 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange+Schenk+FS-Röhrenbestückung
Literature/Schematics (1) -- Original-techn. papers.
Picture reference Eine Abbildung findet sich im Doppelband "Radio von gestern"


All listed radios etc. from Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Here you find 3421 models, 2983 with images and 1969 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
