Admiral 346WL (T346WL)

Admiral 346WL ; Telefunken (ID = 21735) Radio

Admiral 346WL ; Telefunken (ID = 21736) Radio

Admiral 346WL ; Telefunken (ID = 238721) Radio

Admiral 346WL ; Telefunken (ID = 238722) Radio

Admiral 346WL ; Telefunken (ID = 243904) Radio

Admiral 346WL ; Telefunken (ID = 7625) Radio

Admiral 346WL ; Telefunken (ID = 718162) Radio

Admiral 346WL ; Telefunken (ID = 718163) Radio
Admiral 346WL ; Telefunken (ID = 18272) Radio Admiral 346WL ; Telefunken (ID = 18273) Radio
Admiral 346WL ; Telefunken (ID = 18274) Radio Admiral 346WL ; Telefunken (ID = 65814) Radio
Admiral 346WL ; Telefunken (ID = 65815) Radio Admiral 346WL ; Telefunken (ID = 68183) Radio
Admiral 346WL ; Telefunken (ID = 757760) Radio Admiral 346WL ; Telefunken (ID = 757761) Radio
Admiral 346WL ; Telefunken (ID = 757762) Radio Admiral 346WL ; Telefunken (ID = 946868) Radio
Use red slider bar for more.
Admiral 346WL ; Telefunken (ID = 18272) Radio
Telefunken: Admiral 346WL [Radio] ID = 18272 796x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Admiral 346WL (T346WL), Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1933/1934 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: RENS1234 RENS1234 REN914 RENS1374d RGN1064
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown); 2 Special; 1 AF stage(s); Anode bend detection
Tuned circuits 3 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110, 125, 150, 220, 240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: Admiral 346WL - Telefunken Deutschland TFK,
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 440 x 325 x 305 mm / 17.3 x 12.8 x 12 inch
Notes

Parallelgerät zum AEG Ultra-Geadem 304WL in anderem Gehäuse.
Parallelgerät zum Siemens Ätherzepp 47WL in anderem Gehäuse.

Net weight (2.2 lb = 1 kg) 15.1 kg / 33 lb 4.2 oz (33.26 lb)
Price in first year of sale 263.00 RM !
Collectors' prices
Source of data Radio-Zentrale Prohaska 1933/34 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange+Schenk+FS-Röhrenbestückung
Literature/Schematics (1) -- Original-techn. papers. (Telefunken-Werkstattbuch)
Picture reference Eine Abbildung findet sich im Doppelband "Radio von gestern"


All listed radios etc. from Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Here you find 3416 models, 2982 with images and 1964 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
