Allegro 2183 hell

Allegro 2183; Telefunken (ID = 190712) Radio

Allegro 2183; Telefunken (ID = 190713) Radio

Allegro 2183; Telefunken (ID = 190714) Radio

Allegro 2183; Telefunken (ID = 190715) Radio

Allegro 2183; Telefunken (ID = 190716) Radio

Allegro 2183; Telefunken (ID = 190717) Radio

Allegro 2183; Telefunken (ID = 1797773) Radio

Allegro 2183; Telefunken (ID = 1797775) Radio

Allegro 2183; Telefunken (ID = 1803349) Radio

Allegro 2183; Telefunken (ID = 1803350) Radio
Allegro 2183; Telefunken (ID = 13628) Radio Allegro 2183; Telefunken (ID = 63087) Radio
Allegro 2183; Telefunken (ID = 1075552) Radio Allegro 2183; Telefunken (ID = 2326542) Radio
Allegro 2183; Telefunken (ID = 2326543) Radio
Use red slider bar for more.
Allegro 2183; Telefunken (ID = 13628) Radio
Telefunken: Allegro 2183 [Radio] ID = 13628 417x369
Select picture or schematic to display from thumbnails on the right and click for download.
For model Allegro 2183 hell, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH:
Quelle:Servicedokumentation

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1960/1961 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: ECC85 ECH81 EBF89 ECC83 EM84 EBC91 EL84 ECL86
Semiconductors (the count is only for transistors) OA172 OA172
Main principle Superheterodyne (common); ZF/IF 460 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Allegro 2183 [hell] - Telefunken Deutschland TFK,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 590 x 360 x 245 mm / 23.2 x 14.2 x 9.6 inch
Notes

Nussbaum, hell mattiert.
Parallelgerät zum AEG Midinette 61.

Net weight (2.2 lb = 1 kg) 10.7 kg / 23 lb 9.1 oz (23.568 lb)
Price in first year of sale 368.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1960/61
Literature/Schematics (1) -- Original-techn. papers.


All listed radios etc. from Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Here you find 3449 models, 3033 with images and 2025 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.





Forum contributions about this model
Telefunken: Allegro 2183
Threads: 1 | Posts: 3
Hits: 1365     Replies: 2
telefunken: 2183; Allegro
Richard Joltes
02.Sep.15
  1

I acquired one of these units, but it was delivered with no power cable attached. Even with the schematic I cannot tell where the power should be connected to the unit; if someone could provide this information (descriptive or a photo) I'd be very grateful. It's not the same as the 5183, which is the US variant, as far as I can determine.



Wolfgang Bauer
02.Sep.15
  2

Hello Richard,

Look at the diagram and image.
Use the connections "R" and "S" on the insulating srew joint.

Regards WB.

Richard Joltes
02.Sep.15
  3

Hi Wolfgang,

Thanks for the diagram. I thought this had to be the case, and that the switch was inline with one leg of the power cord.

Very interesting difference between this and the 5183 export radio, which has an interlock power connector in the empty rectangle on the power supply. I have two power supplies, one for each type of set, and the rest of the electronics are from a 5183. It appears the schematics are identical between the two aside from the supply (the 5183 does not have the large silver capacitor either).

My problem is that the set emits a 60hz hum when powered on, and I haven't been able to isolate whether it's from the power supply or on the board. I wanted to test using the 2183 supply, but it fails to operate the unit when powered on.

More diagnostics needed, apparently. Any suggestions appreciated!

Best,


Richard


Telefunken: Allegro 2183
End of forum contributions about this model
