Concerto ; Telefunken (ID = 167049) Radio
Telefunken: Concerto [Radio] ID = 167049 933x657
Select picture or schematic to display from thumbnails on the right and click for download.
For model Concerto, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1956/1957 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EF89 EF89 EM80 EABC80 EL84
Semiconductors (the count is only for transistors) B250C75
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 8 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110, 125, 150, 220, 240 Volt
Loudspeaker 3 Loudspeakers
Power out 5.5 W (unknown quality)
from Radiomuseum.org Model: Concerto - Telefunken Deutschland TFK,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 630 x 415 x 295 mm / 24.8 x 16.3 x 11.6 inch
Notes

Bandbreite schaltbar; KW-Lupe; drehbare Ferritantenne. Technische Ausführung wie Concertino 7, jedoch in modernem hellem Gehäuse.

Net weight (2.2 lb = 1 kg) 15 kg / 33 lb 0.6 oz (33.04 lb)
Price in first year of sale 439.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1956/57
