- Country
- Germany
- Manufacturer / Brand
- Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
- Year
- 1962/1963
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 107648
- Number of Tubes
- 20
- Valves / Tubes
- PCC88 PCF82 PC88 PC86 PCF82 EF80 EBC91 PL82 EF85 EF85 EF184 PCL84 ECH84 PCL85 ECH84 EAA91 PL500 PY88 DY86 AW59-90
- Number of Transistors
- Main principle
- Superheterodyne (common); ZF/IF 38900 kHz
- Wave bands
- Wave Bands given in the notes.
- Details
- Radio Control (+Remote Wire etc)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: FE242St - Telefunken Deutschland TFK,
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 860 x 910 x 470 mm / 33.9 x 35.8 x 18.5 inch
- Notes
-
VHF/UHF. Technische Daten wie FE242T, jedoch Standgerät mit abschließbaren Jalousietüren.
Anschluss für Fernregler FR 6 (Regelung von Lautstärke und Helligkeit).
- Net weight (2.2 lb = 1 kg)
- 42 kg / 92 lb 8.2 oz (92.511 lb)
- Price in first year of sale
- 1,498.00 DM
- Source of data
- Handbuch VDRG 1962/1963
- Mentioned in
- -- Original-techn. papers. (TFK Fernseh-Service FVH62-2242)
- Author
- Model page created by Bernd P. Kieck. See "Data change" for further contributors.
