Linear 303
Use red slider bar for more.
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1961 | Category: Television Receiver (TV) or Monitor | ||||
| Valves / Tubes | 17: 6AF4A ECC88 ECF80 EF80 EF80 EF80 EL84 ECC82 ECL85 EL84 EABC80 EF80 ECC82 6DQ6GT 6AU4GTA 1G3GT 23CP4 | ||||
|---|---|---|---|---|---|
| Semiconductors (the count is only for transistors) | 17: |
| Main principle | Superheterodyne (common); ZF/IF 45750/40250 kHz |
|---|---|
| Wave bands | VHF incl. FM and/or UHF (see notes for details) |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 125; 140; 160; 220; 240 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical |
| Power out | |
| from Radiomuseum.org | Model: Linear 303 - Voxson F.A.R.E.T., Roma |
| Material | Wooden case |
| Shape | Tablemodel, low profile (big size). |
| Dimensions (WHD) | 730 x 530 x 360 mm / 28.7 x 20.9 x 14.2 inch |
| Notes | Cinescopio da 23" con deflessione a 110° e focalizzazione elettrostatica automatica. Gruppo sintonizzatore per la ricezione dei canali VHF a 13 posizioni. Gruppo sintonizzatore per la ricezione della gamma UHF incorporato. |
| Net weight (2.2 lb = 1 kg) | 33 kg / 72 lb 11 oz (72.687 lb) |
| Literature/Schematics (1) | -- Original-techn. papers. |
Model page created by Eduard Abfalterer. See "Data change" for further contributors.
All listed radios etc. from Voxson F.A.R.E.T., Roma
Here you find 147 models, 122 with images and 76 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
