Atrium 654; Loewe-Opta; (ID = 1549228) Television
Loewe-Opta;: Atrium 654 [Television] ID = 1549228 933x923
Select picture or schematic to display from thumbnails on the right and click for download.
For model Atrium 654, Loewe-(Opta); Deutschland

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1958/1959 Category: Television Receiver (TV) or Monitor
Valves / Tubes 17: PCC88 PCF80 EF80 EF80 EF80 PCL81 EF80 PABC80 PL82 ECH81 ECC82 PL36 PY81 DY86 ECH81 PCL82 AW53-80
Main principle Superheterodyne (common); ZF/IF 38900 kHz; 1 AF stage(s)
Wave bands Wave Bands given in the notes.
Details Radio Control (+Remote Wire etc)
Power type and voltage AC/DC-set / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 22 cm = 8.7 inch
Power out
from Radiomuseum.org Model: Atrium 654 - Loewe-Opta; Deutschland
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 600 x 530 x 510 inch / 15240 x 13462 x 12954 mm
Notes Technische Daten wie Iris 651, jedoch mit 53-cm-Bildröhre.
Net weight (2.2 lb = 1 kg) 38 kg / 83 lb 11.2 oz (83.7 lb)
Price in first year of sale 968.00 DM
Source of data HdB d.Rdf-& Ferns-GrH 1958/59

Model page created by Florian Langer. See "Data change" for further contributors.
