UKW-Magnetophonschrank FA833A

Philips - Österreich

Data
Forum
Pictures
Collections

  • Year
  • 1953
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 79512

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 16
  • Main principle
  • Superheterodyne (common)
  • Tuned circuits
  • 6 AM circuit(s)     9 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Details
  • Record Player + Tape Recorder
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 130; 150; 220; 240 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: UKW-Magnetophonschrank FA833A - Philips - Österreich
  • Shape
  • Console, Lowboy (legs < 50 %).
  • Notes

  • Mit Plattenwechsler Philips AG1000 und Tonbandgerät Maestro-Junior (5Rö: EF40 EF42 EL41 AZ41 EM34, Bandgeschw. 9,5 cm/sec). Kurzwellenlupe. Konzertlautsprecher in Schallbox.

    Siehe auch Magnetophonschrank FA821A ohne UKW-Bereich.

  • Price in first year of sale
  • 15,000.00 öS
  • Source of data
  • -- Original prospect or advert / Radiokatalog Band 2, Ernst Erb
  • Literature/Schematics (4)
  • -- Schematic
  • Author
  • Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
