Futurist (Serie Photomatic) T-301

Futurist T-301; Voxson F.A.R.E.T., (ID = 1111683) Television

Futurist T-301; Voxson F.A.R.E.T., (ID = 1111684) Television

Futurist T-301; Voxson F.A.R.E.T., (ID = 1111685) Television

Futurist T-301; Voxson F.A.R.E.T., (ID = 1111686) Television

Futurist T-301; Voxson F.A.R.E.T., (ID = 1111687) Television

Futurist T-301; Voxson F.A.R.E.T., (ID = 1111688) Television

Futurist T-301; Voxson F.A.R.E.T., (ID = 1111689) Television

Futurist T-301; Voxson F.A.R.E.T., (ID = 1111690) Television

Futurist T-301; Voxson F.A.R.E.T., (ID = 1111691) Television

Futurist T-301; Voxson F.A.R.E.T., (ID = 1111692) Television
Futurist T-301; Voxson F.A.R.E.T., (ID = 2313831) Television
Use red slider bar for more.
Futurist T-301; Voxson F.A.R.E.T., (ID = 2313831) Television
Voxson F.A.R.E.T.,: Futurist T-301 [Television] ID = 2313831 678x519
Select picture or schematic to display from thumbnails on the right and click for download.
For model Futurist (Serie Photomatic) T-301, Voxson F.A.R.E.T., Roma:
Televisore Voxson T-301

Country:  Italy
Manufacturer / Brand:  Voxson F.A.R.E.T., Roma
Year: 1968 ?? Category: Television Receiver (TV) or Monitor
Valves / Tubes 20: 6AF4A ECC189 ECF80 EF80 EF80 EF80 EL84 EAA91 ECC83 ECF80 EABC80 EL84 EF80 ECC82 ECC82 EL84 6DQ6 6AU4GTA 1B3GT 23CP4
Main principle Superheterodyne (common); ZF/IF 45750/40250 kHz
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 125; 140; 160; 220; 260 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Futurist T-301 - Voxson F.A.R.E.T., Roma
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 760 x 460 x 350 mm / 29.9 x 18.1 x 13.8 inch
Notes Cinescopio da 23" con deflessione a 110° e focalizzazione elettrostatica automatica.
Gruppo sintonizzatore per la ricezione dei canali VHF a 13 posizioni.
Gruppo sintonizzatore per la ricezione della gamma UHF incorporato.
Comando a distanza ad ultrasuoni Spatial Control mod. SC88.
Net weight (2.2 lb = 1 kg) 40 kg / 88 lb 1.7 oz (88.106 lb)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Eduard Abfalterer. See "Data change" for further contributors.



All listed radios etc. from Voxson F.A.R.E.T., Roma
Here you find 147 models, 122 with images and 76 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
