Gran Gala (Serie Photomatic) T-302

Gran Gala T-302; Voxson F.A.R.E.T., (ID = 1112039) Television

Gran Gala T-302; Voxson F.A.R.E.T., (ID = 1112040) Television

Gran Gala T-302; Voxson F.A.R.E.T., (ID = 1112041) Television

Gran Gala T-302; Voxson F.A.R.E.T., (ID = 1112042) Television

Gran Gala T-302; Voxson F.A.R.E.T., (ID = 1112043) Television

Gran Gala T-302; Voxson F.A.R.E.T., (ID = 1112044) Television

Gran Gala T-302; Voxson F.A.R.E.T., (ID = 1112046) Television

Gran Gala T-302; Voxson F.A.R.E.T., (ID = 1112047) Television

Gran Gala T-302; Voxson F.A.R.E.T., (ID = 1112048) Television

Gran Gala T-302; Voxson F.A.R.E.T., (ID = 1112049) Television
Gran Gala T-302; Voxson F.A.R.E.T., (ID = 2313826) Television Gran Gala T-302; Voxson F.A.R.E.T., (ID = 2313828) Television
Use red slider bar for more.
Gran Gala T-302; Voxson F.A.R.E.T., (ID = 2313826) Television
Voxson F.A.R.E.T.,: Gran Gala T-302 [Television] ID = 2313826 981x667
Select picture or schematic to display from thumbnails on the right and click for download.
For model Gran Gala (Serie Photomatic) T-302, Voxson F.A.R.E.T., Roma:
Televisore Voxson Photomatic

Country:  Italy
Manufacturer / Brand:  Voxson F.A.R.E.T., Roma
Year: 1968 ?? Category: Television Receiver (TV) or Monitor
Valves / Tubes 20: 6AF4A ECC189 ECF80 EF80 EF80 EF80 EL84 EAA91 ECC83 ECF80 EABC80 EL84 EF80 ECC82 ECC82 EL84 6DQ6 6AU4GTA 1B3GT 23CP4
Main principle Superheterodyne (common); ZF/IF 45750/40250 kHz
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 125; 140; 160; 220; 260 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Gran Gala T-302 - Voxson F.A.R.E.T., Roma
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 760 x 440 x 350 mm / 29.9 x 17.3 x 13.8 inch
Notes Cinescopio da 23" con deflessione a 110° e focalizzazione elettrostatica automatica.
Gruppo sintonizzatore per la ricezione dei canali VHF a 13 posizioni.
Gruppo sintonizzatore per la ricezione della gamma UHF incorporato.
Net weight (2.2 lb = 1 kg) 40 kg / 88 lb 1.7 oz (88.106 lb)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Eduard Abfalterer. See "Data change" for further contributors.
