Balmoral Radio Gramophone 7070/W/3D GB

Grundig Ltd., London

Data
Forum
Pictures
Collections

  • Year
  • 1956 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 361354

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Number of Transistors
  • Main principle
  • Superheterodyne (common); ZF/IF 468/10700 kHz
  • Tuned circuits
  • 6 AM circuit(s)     9 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 200; 220; 240 Volt
  • Loudspeaker
  • 5 Loudspeakers
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Balmoral Radio Gramophone 7070/W/3D GB - Grundig Ltd., London
  • Shape
  • Console with Push Buttons.
  • Notes

  • Record deck is Collaro RC54 using Collaro studio O crystal cartridge.

    This Grundig Radio Gram has a total of 5 loudspeakers: 1 Woofer, 2 midrange and 2 electrostatic tweeters.

    The table model Hastings 2035W/3D/GB shares a similar chassis.

  • Mentioned in
  • - - Manufacturers Literature
  • Literature/Schematics (1)
  • - - Manufacturers Literature
  • Author
  • Model page created by Mike Tonkin. See "Data change" for further contributors.
