Reverbeo B7X14A /79
Use red slider bar for more.
Philips Belgium: Reverbeo B7X14A /79 [Radio] ID = 2579458 1400x697
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1961–1963 ? | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 10: ECC85 ECH81 EF89 EBF89 EM80 EAA91 ECC83 EL84 EL84 EZ81 | ||||
|---|---|---|---|---|---|
| Semiconductors (the count is only for transistors) | 1: OC71 |
| Main principle | Superheterodyne (common); ZF/IF 460/10700 kHz |
|---|---|
| Tuned circuits | 6 AM circuit(s) 11 FM circuit(s) |
| Wave bands | Broadcast, Long Wave, Short Wave plus FM or UHF. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 110 - 240 Volt |
| Loudspeaker | 2 Loudspeakers / Ø 21 cm = 8.3 inch |
| Power out | |
| from Radiomuseum.org | Model: Reverbeo B7X14A /79 - Philips Belgium Belgien |
| Material | Wooden case |
| Shape | Tablemodel with Push Buttons. |
| Dimensions (WHD) | 710 x 265 x 290 mm / 28 x 10.4 x 11.4 inch |
| Notes | Modell für den schweizer Markt mit FM bis 104 MHz. Skala mehrsprachig italienisch / französisch / deutsch. Siehe auch die Versionen
|
| Net weight (2.2 lb = 1 kg) | 14 kg / 30 lb 13.4 oz (30.837 lb) |
Model page created by Lutz Weseloh. See "Data change" for further contributors.
