Opus 7; Telefunken (ID = 95202) Radio
Telefunken: Opus 7 [Radio] ID = 95202 640x480
Wählen Sie rechts durch klick. Mitglieder klicken für Download in gross.
Für Modell Opus 7, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Land:  Deutschland / Germany
Hersteller / Marke:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Jahr: 1956/1957 Kategorie: Rundfunkempfänger (Radio - oder Tuner nach WW2)
Röhren 9: ECC85 ECH81 EF89 EF89 EM80 EABC80 EC92 EL84 EL84
Halbleiter (Zählung nur für Transistoren) B250C125
Hauptprinzip Superhet allgemein; ZF/IF 460/10700 kHz
Anzahl Kreise 8 Kreis(e) AM     12 Kreis(e) FM
Wellenbereiche Langwelle, Mittelwelle, Kurzwelle und UKW.
Betriebsart / Volt Wechselstromspeisung / 110; 125; 150; 220; 240 Volt
Lautsprecher 6 Lautsprecher
Belastbarkeit / Leistung
von Modell: Opus 7 - Telefunken Deutschland TFK,
Material Gerät mit Holzgehäuse
Form Tischgerät, Tasten oder Druckknöpfe.
Abmessungen (BHT) 660 x 415 x 280 mm / 26 x 16.3 x 11 inch

KW-Lupe; Bandbreite schaltbar; drehbare Ferritantenne;
Chassis baugleich mit AEG 5086WD.

Please look up Opus 7 grille bar USA and Opus 7 textil bar USA for the export version with the SAMS schematic.

Nettogewicht 15.8 kg / 34 lb 12.8 oz (34.802 lb)
Originalpreis 519.00 DM
Datenherkunft extern Erb
Datenherkunft HdB d.Rdf-& Ferns-GrH 1956/57
Literatur/Schema (1) -- Original-techn. papers.

Alle gelisteten Radios usw. von Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Hier finden Sie 3471 Modelle, davon 3040 mit Bildern und 2008 mit Schaltbildern.


Forumsbeiträge zum Modell
Telefunken: Opus 7
Threads: 1 | Posts: 3
Klicks: 5552     Antworten: 2
telefunken: Opus 7
Bill Raukko

I am repairing a Telefunken Opus 7 radio, and have the schematic, but the radio is out of alignment.  The schematic refers to "Alignment instructions S 3096".  Does anyone know where I can find this service information?  Hopefully they are available in English.  Thank you.

Bill Raukko


Omer Suleimanagich

Check the Sams upload for the Opus 6.

Ernst Erb

Dear Bill
Omer is right: When you look on our Schematic Finder, it will indicate where to find the schematic. You find this link on the main page under "Radiomuseum" (7th link).

You just type Opus 7 to the field "Model" and you get the answer:
SAMS Photoshop Set 341, folder 16, Date 12-56 for Telefunken Opus 7.

You have posted this to the domestic model instead to the USA model of Opus 7 and therefore will not find the SAMS schematic here - but the schematics in German.

If you use the "Simple search for Antique Radios etc." and just type opus 7 you will get both on your hit list. Since I have here all SAMS in 51 big binders from Beginning to set 510 I will be able to scan, prepare and load up the set 341 for you - if you did not already get it.

We are working hard in Austria, Germany and Switzerland to get those SAMS up from the beginning to the End of 1963 methodically, but we miss help from the USA.
If there is anone out there who would like to help us a bit - he/she would be most welcome to write to me by using the link below a post "Mail to the author".

Please can you take out your eMail address from this post by using "Edit" - since one can get to you by this means anytime? It is not good practise to publish an eMail-address - even if we automatically change the @. Otehrs would follow - and sooner or later will get SPAM ...

Opus 6 and Opus 7
The mentioned schematics are titled "Opus No. 6 (Ch. A, B)" but in the Photofact Annual Index you find listed both models, Opus 6 and Opus 7 for the same schematic. I did not check the schematics in German - but at least the tube line up is the same.

This thread:
I leave it on the wrong model for others to come to the domestic model instead of the USA version. They can use the link above to get to the right model.

Telefunken: Opus 7
Ende Forumsbeiträge zum Modell
