Corona 7245 Rdf.-Ch= Milano Ausführung B

Corona 7245 Rdf.-Ch= Milano; Blaupunkt Ideal, (ID = 2514859) TV Radio

Corona 7245 Rdf.-Ch= Milano; Blaupunkt Ideal, (ID = 2514860) TV Radio

Corona 7245 Rdf.-Ch= Milano; Blaupunkt Ideal, (ID = 2514861) TV Radio

Corona 7245 Rdf.-Ch= Milano; Blaupunkt Ideal, (ID = 2514862) TV Radio
Corona 7245 Rdf.-Ch= Milano; Blaupunkt Ideal, (ID = 207623) TV Radio Corona 7245 Rdf.-Ch= Milano; Blaupunkt Ideal, (ID = 1028295) TV Radio
Use red slider bar for more.
Corona 7245 Rdf.-Ch= Milano; Blaupunkt Ideal, (ID = 207623) TV Radio
Blaupunkt Ideal,: Corona 7245 Rdf.-Ch= Milano [TV Radio] ID = 207623 578x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Corona 7245 Rdf.-Ch= Milano Ausführung B, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1955/1956 Category: Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
Valves / Tubes 23: PCC84 PCF82 EF80 EF80 EF80 PCL81 EAA91 ECL80 PCL81 ECC81 PL81 PY83 DY80 EF80 PABC80 PL82 MW43-69 or Bmv42/4 ECC85 ECH81 EF89 EABC80 EM80 EL84
Main principle Superhet with RF-stage; ZF/IF 38900/33400/5500 kHz
Wave bands Wave Bands given in the notes.
Details Record Player (not changer); Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Corona 7245 Rdf.-Ch= Milano [Ausführung B] - Blaupunkt Ideal, Berlin,
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 1065 x 920 x 560 mm / 41.9 x 36.2 x 22 inch
Notes

43-cm-Standgerät mit Rundfunk- und Phonoteil.
TV-Chassis = Malta 7220 Ausf. B;
Radio-Chassis = Milano 2225;
Phono-Chassis = k. A.

Blaupunkt Fernbedienung FG 211 anschließbar

Net weight (2.2 lb = 1 kg) 57 kg / 125 lb 8.8 oz (125.551 lb)
Price in first year of sale 1'525.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1955/56
Mentioned in Katalog Thiele,Helmstedt 1955/56 (S.94)
Literature/Schematics (1) -- Original-techn. papers.
