For model Bodensee Vollautomatic 12V Sonorama, SABA; Villingen:
ebay 300254828576 Verkäufer dammung

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1962/1963 Category: Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
Valves / Tubes PCC88 PCF80 PCF82 EF183 EF80 PCL84 EBF89 ECH84 PCL85 PL500 PY88 DY86 PCL86 PC88 PC86 AW59-90 ECC83 ECC83 EL95 EM87 or EM84a EC92 EC92 ECH81 EF89 EM84 EBF89 EF86 EF86 ECC83 ELL80 ELL80 EABC80 ECL80
Semiconductors (the count is only for transistors) TF65 TF65
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details Changer + Tape Recorder; Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 6 Loudspeakers
Power out
from Radiomuseum.org Model: Bodensee Vollautomatic 12V Sonorama - SABA; Villingen
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Dimensions (WHD) 1815 x 885 x 465 mm / 71.5 x 34.8 x 18.3 inch
Notes

Abgleich (auch Steuerfilter)
Alignment (also automatic filter)

Röhren- und Transistorangaben für beide Ausstattungsvarianten (TK125-4 und TK25S)

Die Variante mit TK125-4 ist nur mit einer ECC85 und nur einem Transistor TF65, sowie mit einer EM84a anstelle der EM87 ausgestattet.

Net weight (2.2 lb = 1 kg) 127 kg / 279 lb 11.8 oz (279.736 lb)
Price in first year of sale 3'279.00 DM
Collectors' prices
Source of data Handbuch VDRG 1962/1963


All listed radios etc. from SABA; Villingen
Here you find 1546 models, 1402 with images and 1035 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
SABA; Villingen: Bodensee Vollautomatic 12V Sonorama
Threads: 1 | Posts: 1
Hits: 2118     Replies: 0
saba: 12V Sonor; Bodensee Vollautomatic
Franz-Josef Haffner
12.Sep.03
  1

weitere technische Unterlagen siehe Modell Freiburg 12:

http://www.radiomuseum.org/dsp_modell.cfm?model_id=24359
