For model Bodensee 7 1956, SABA; Villingen:
Saba Reporter 12

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1956/1957 Category: Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
Valves / Tubes 24: PCC84 PCF82 EF80 EF80 EF80 PCL81 ECL80 PCL82 PCL82 PL81 PY81 EY86 EF80 EF80 PABC80 MW43-69 EC92 EC92 ECH81 EF85 EABC80 EM80 EL84 EZ80
Main principle Super-Heterodyne (Super in general); ZF/IF 38900/460/6750 kHz
Wave bands Wave Bands given in the notes.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 125; 150; 220 Volt
Loudspeaker 2 Loudspeakers / Ø 20 cm = 7.9 inch
Power out
from Radiomuseum.org Model: Bodensee 7 [1956] - SABA; Villingen
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 1100 x 846 x 538 mm / 43.3 x 33.3 x 21.2 inch
Notes

Fernseh-Chassis = Schauinsland T604;
Rundfunk-Chassis = Freudenstadt 7;
Phono-Chassis = Dual 1003.

Net weight (2.2 lb = 1 kg) 77 kg / 169 lb 9.7 oz (169.604 lb)
Price in first year of sale 1,899.00 DM
Collectors' prices
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1956/57
