Kombinationsmöbel CFS2184A Ch= C2-H (TV) Ch= B3 (radio)

Kombinationsmöbel CFS2184A Ch= C2-H Ch= B3 ; Philips, Svenska AB, (ID = 1710672) TV Radio Kombinationsmöbel CFS2184A Ch= C2-H Ch= B3 ; Philips, Svenska AB, (ID = 1710671) TV Radio
Kombinationsmöbel CFS2184A Ch= C2-H Ch= B3 ; Philips, Svenska AB, (ID = 1710673) TV Radio Kombinationsmöbel CFS2184A Ch= C2-H Ch= B3 ; Philips, Svenska AB, (ID = 1710656) TV Radio
Kombinationsmöbel CFS2184A Ch= C2-H Ch= B3 ; Philips, Svenska AB, (ID = 1710660) TV Radio Kombinationsmöbel CFS2184A Ch= C2-H Ch= B3 ; Philips, Svenska AB, (ID = 1710665) TV Radio
Kombinationsmöbel CFS2184A Ch= C2-H Ch= B3 ; Philips, Svenska AB, (ID = 1710669) TV Radio Kombinationsmöbel CFS2184A Ch= C2-H Ch= B3 ; Philips, Svenska AB, (ID = 1710674) TV Radio
Kombinationsmöbel CFS2184A Ch= C2-H Ch= B3 ; Philips, Svenska AB, (ID = 1710676) TV Radio Kombinationsmöbel CFS2184A Ch= C2-H Ch= B3 ; Philips, Svenska AB, (ID = 1710677) TV Radio
Use red slider bar for more.
Kombinationsmöbel CFS2184A Ch= C2-H Ch= B3 ; Philips, Svenska AB, (ID = 1710672) TV Radio
Philips, Svenska AB,: Kombinationsmöbel CFS2184A Ch= C2-H Ch= B3 [TV Radio] ID = 1710672 800x871
Select picture or schematic to display from thumbnails on the right and click for download.
For model Kombinationsmöbel CFS2184A Ch= C2-H (TV) Ch= B3 (radio), Philips, Svenska AB, Stockholm:
Mit freundlicher Genehmigung von Ebay Mitglied "geldverschwenden" Auktion Nummer 111444739056

Country:  Sweden
Manufacturer / Brand:  Philips, Svenska AB, Stockholm
Year: 1958 ? Category: Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
Valves / Tubes 26: ECC85 ECH81 EBF89 ECC83 EM80 EL86 EL84 PCC88 or E88CC PCF80 EF80 EF80 EF80 EF80 PL83 PCF80 ECH81 PCL82 PCF80 PCF80 PL84 PL84 PCF80 PL36 PY81 EY87 AW53-80
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10850/38900 kHz
Wave bands Wave Bands given in the notes.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Kombinationsmöbel CFS2184A Ch= C2-H Ch= B3 - Philips, Svenska AB, Stockholm
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Dimensions (WHD) 775 x 1065 x 604 mm / 30.5 x 41.9 x 23.8 inch
Notes

TV: VHF channel 2-12 (53,75 - 222,75MHz)
Radio: LW, MW, SW and FM.

Loudspeaker: 1x double conus 156 mm, 1x elliptical 146x219 mm.
Power consumption: TV 185 W, radio 70 W.
Cabinet: Teak

Net weight (2.2 lb = 1 kg) 73.1 kg / 161 lb 0.2 oz (161.013 lb)
Mentioned in - - Manufacturers Literature (Service manual)

Model page created by Jochen Amend. See "Data change" for further contributors.
